Two shapes of round and square are available,A bread light that illuminates a wide area

No Video flash
Uniform illumination
Constant current stabilization

Feature

  • No Video flash

  • Three to five years warranty

  • Brand driven, constant flow and stability

  • Surface mounted, no holes required, no damage to the ceiling

  • Die-cast aluminum lamp body, fast heat dissipation, reduce light decay, extend the service life of the lamp



Application

  • Shop

  • supermarket

  • Kitchen / Rest room

  • Passageway / corridor



Data

Item No. Power Voltage Luminous efficiency Size
HYD-112R-6W 6W 220-240V 90-120 lm/w 120*40 mm
HYD-112R-12W 12W 220-240V 90-120 lm/w 170*40 mm
HYD-112R-18W 18W 220-240V 90-120 lm/w 225*40 mm
HYD-112R-24W 24W 220-240V 90-120 lm/w 300*40 mm
HYD-112S-6W 6W 220-240V 90-120 lm/w 120*120*40 mm
HYD-112S-12W 12W 220-240V 90-120 lm/w 170*170*40 mm
HYD-112S-18W 18W 220-240V 90-120 lm/w 225*225*40 mm
HYD-112S-24W 24W 220-240V 90-120 lm/w 300*300*40 mm





High quality bread lamp, the use of die-cast aluminum lamp body design, enhance the heat dissipation effect, reduce the light decay of the lamp bead, effectively extend the service life of the lamp, it has three to five years of warranty, can reduce the number of user replacement.



Choose brand drive, such as Igor, Lyford, safety and other well-known brands, luminous stability.



Open-mounted panel light, no need to open holes, effectively protect the integrity of the ceiling, its high brightness, irradiation area is wide, often used in bedrooms, bathrooms, kitchens, libraries and stores.



Installation:Surface mounted



Package Data



Product code Packaging unit (pieces/Unit) Dimensions (length x width x height) Volume
112R-24W Graphic carton 32.5*5*31 cm 0.00504
10
Master carton 64*27*35 cm 0.06048
1
112S-18W Graphic carton 24.5*5*24.5 cm 0.00300
10
Master carton 51*26.5*27.5 cm 0.03717
1



Graphic carton

112R-24W





112S-18W



Panel light



Master carton

112R-24W



Panel light



112S-18W



Panel light
